Process

Incineration is that solid wastes transform into inert residue under the high temperature combustion and utilize the combustion waste heat. The incineration flows are as follows: Waste is thrown into the furnace by the feeding device, and the furnace starts to dry and carry out the pyrolysis once ignited. The pyrolysis flammable gas is burnt sufficiently in the secondary combustion chamber. Acid gas is turned into non-acid gas in semi-dry quenching acid-adsorption tower before entering into the Bag Dust Collector; then, active carbon powder is sprayed into the dust collector to get rid of the Dioxin. Then, the clean gas is discharged out of the chimney by the induced draft.

System Components

● Waste Receiving System

● Incineration System

● Waste Heat Boiler System

● Combustion Air System

● Turbine Power Generation System

● Flue Gas Purification System

● Ash and Leachate Treatment System

● Steam and Condensate System

● Scrap Metal Recovery System

● Automatic Control and Instrumentation System
